F1.6 4.0mm 1/2.7" M12 Network Camera Lens PL066

F1.6 4.0mm 1/2.7" M12 Network Camera Lens BOSHI LENS  is a leading China Standard M12 Lens manufacturer, supplier and exporter. Adhering to the pursuit of perfect quality of products, so that our Standard M12 Lens have been satisfied by many customers. Extreme design, quality raw materials, high performance and competitive price are what every customer wants, and that's also what we can offer you. We will provide you with the best after-sales service and timely delivery.

F1.6 4.0mm 1/2.7" M12 Network Camera Lens PL066 Dashcam Lens, Standard M12 threaded interface Lens, with 1.6 F/NO, 1G4P structure, more lightweight, with high cost-effectiveness! If you are interested in our Standard Starlight Lens, you can consult us now, we will reply to you in time!

·Featuring a large F1.6 aperture, it ensures high light intake, significantly improving night vision performance and image brightness in low-light conditions.

·With a horizontal FOV of 90° and a diagonal FOV of 106°, it provides a wide coverage area without excessive edge stretching.

·The 1G4P (1 Glass + 4 Plastic) construction balances optical performance (glass for durability and clarity) with the cost-efficiency and lightweight nature of plastic.

·Compatible with 1/2.7" sensors, it fits most mainstream HD/UHD sensors in the market.

I. Product Features and Selling Points

1. Superior Aperture Performance (F1.6)

One of the core selling points of this lens is its large F1.6 aperture. Among M12 lenses, F1.6 represents a significant light-gathering capability. A larger aperture allows the sensor to capture more light in low-light environments (such as dusk, indoors, or nighttime), significantly improving image brightness and reducing digital noise.

2. Hybrid Optical Structure (1G4P)

The lens utilizes a 1 Glass (1G) + 4 Plastic (4P) element configuration.

·1G (1 Glass Element): Usually positioned as the outermost element, glass offers high hardness, scratch resistance, and excellent chemical stability. it protects the inner elements and minimizes "focus shift" caused by environmental temperature fluctuations.

·4P (4 Plastic Elements): Plastic lenses are easier to manufacture into aspheric shapes, which effectively control aberrations and reduce costs while keeping the overall module lightweight. This "Glass-Plastic Hybrid" design balances high imaging quality with cost-efficiency.

3. High-Resolution Compatibility (1.3MP - 5MP)

The lens supports sensors ranging from 1.3 Megapixels to 5 Megapixels. This indicates that its optical resolution is sufficient to support High Definition (1080P) and Ultra HD (5MP) visual requirements. This versatility allows manufacturers to use the same lens across different sensor tiers without redesigning the housing.

4. Wide-Angle Field of View and Compact Design

·FOV: It provides a diagonal field of view (DFOV) of 106° and a horizontal field of view (HFOV) of 90°, categorizing it as a standard wide-angle lens.

·Dimensions: With a TTL (Total Track Length) of only 22.4mm and an M12 interface, it is exceptionally easy to integrate into compact, space-constrained devices.

II. Application Fields

Thanks to its balanced parameters, the PL066 lens can be widely applied in:

·Smart Home: Smart peepholes, video doorbells, and home security cameras. The 106° wide angle is sufficient to cover most of a doorway or a standard room.

·Automotive Imaging: Dashcams or rearview cameras. The large aperture ensures clarity during night driving, while the wide angle reduces blind spots.

·Security Surveillance: Fixed-view monitoring in commercial offices, elevators, or corridors. The 5MP resolution ensures clear facial recognition.

·Industrial & Robotics: Visual obstacle avoidance for vacuum robots or simple QR code recognition and workpiece inspection on assembly lines.

·Video Conferencing: USB cameras for small-to-medium meeting rooms, providing a natural and clear perspective.

III. Summary of Advantages

·Exceptional Low-Light Performance: The $F1.6$ aperture, when paired with the right sensor, excels in low-light conditions, extending the duration of color imaging and reducing reliance on infrared (IR) illumination.

·Optimized Cost-to-Performance Ratio: By using the 1G4P structure, it maintains edge-to-edge sharpness while avoiding the high material costs of an all-glass lens, making it ideal for mass-market production.

·Broad Compatibility: It is designed for 1/2.7" sensors (the most common size for security and automotive sensors) and maintains a CRA (Chief Ray Angle) of < 18°, ensuring compatibility with most CMOS chips while avoiding color shading or vignetting.

·Robust and Compact Form Factor: The M12*P0.5 standard interface is extremely stable, easy to install, and vibration-resistant, making it suitable for mobile or high-movement scenarios.

The product has the following specific characteristics：

1. Product features: Made of all plastic material, while ensuring the quality of the products, we can offer customers a lower purchase price..

2. Product advantages: Large angle, small size, Wide depth of field range.

We are eagerly awaiting your purchase and look forward to providing you with the best cooperation experience and deeper business collaboration.
