China 1/2.7" Manufacturers, Suppliers, Factory

BOSHI Optical Technology presents the PL-02934H-M12, a high performance wide angle fixed lens for 1/4" Image Sensor formats. With 2.9mm Focal Length and F3.4 Aperture, this Wide Angle Optical Lens delivers a 119° Field of View for broad scene coverage in tight spaces. The all glass construction supports thermal stability and consistent image quality. A controlled Chief Ray Angle below 6.63° reduces colour shading with modern CMOS sensors. The Compact Fixed Lens has an 8.9mm total track length and a 2.46mm mechanical back focal distance for M12 Lens Mount integration. BOSHI Optical Technology balances TV Distortion at about 14.27% barrel distortion, a typical value for wide angle optics that digital correction can address. Relative illumination is 30% at the edge for usable brightness in low light. This lens suits Surveillance and Automotive Imaging, embedded vision, security cameras, in vehicle surround view systems, and industrial inspection. The 2.9mm Focal Length and 119° Field of View support dashcams, doorbell cameras, and compact devices. The F3.4 Aperture provides useful depth of field from 0.3m to infinity.

Standard M12 F2.4 2.8mm 1/2.7" Security CCTV Lens, and all products have been tested by MTF instruments, resulting in higher consistency compared to products from other suppliers. You can rest assured to purchase standard M12 lenses from our factory.

Our factory is located in Shangrao Optical Base, Jiangxi Province, China. We are willing to provide you with high-precision optical glass lenses, biconvex lenses, planoconvex lenses, planoconvex lenses, and meniscus lenses of various materials. Plastic aspheric lenses injection molding optical lenses include: VR, TOF lenses, collimating lenses, beam combining lenses, red outer distance meter compound eye array lenses, TIR lenses, Injection-molded optical lenses can also be used for transmitting and receiving optical instruments, infrared distance measuring instruments, radar systems, and non-standard manufacturing products in injection-molded optical lenses, which can be processed, designed and customized according to customer drawings.

F2.0 4.0mm 1/2.7" M12 Network Camera Lens PL057 is a high-performance, cost-effective M12 fixed-focus lens. PL066's key selling points are the F2.0 large aperture for superior low-light imaging and a 83° horizontal FOV for wide coverage. Featuring a 1G4P hybrid structure and supporting up to 5MP resolution, F2.0 4.0mm 1/2.7" M12 Network Camera Lens PL057 is highly competitive in security, automotive dashcams, and smart home applications where high definition and compactness are essential.

4K/5K M12 Lens is with 1/2.8" 2.65mm UHD 12mp, 4K/5K M12 Lens is 2.65 mm with F2.6 m12 s-mount, 4K/5K M12 Lens is 12megapixel Ultra HD 12M, 4K/5K M12 Lens is M12x0.5 mount cctv board lens.

2.85mm 1/2.9" M12 F2.3 Security Lens PL071, and all products have been tested by MTF instruments, resulting in higher consistency compared to products from other suppliers. You can rest assured to purchase standard M12 lenses from our factory.
