China M22×0.5 Lens Manufacturers, Suppliers, Factory

xThe PL-2445D-M9 is a compact fixed-focal lens engineered by BOSHI Optical Technology for high-resolution industrial imaging. With a 24mm focal length and F/4.5 aperture, this lens delivers exceptional clarity and consistent brightness across a 1/2.5" sensor, covering a maximum image circle of Ø7.4mm. Its all-glass (3-element) construction ensures thermal stability and superior transmission, while the M9 thread mount (P0.35) provides reliable mechanical integration into space‑constrained systems. The lens offers a narrow field of view (16.7° diagonal) ideal for long‑distance inspection, with a TV distortion of merely -0.05% and relative illumination of 97.0% – values that guarantee faithful geometric reproduction and minimal vignetting. The chief ray angle (CRA) stays below 6.6°, ensuring excellent compatibility with modern sensor micro‑lens arrays. Whether deployed in automated optical inspection, precision metrology, or surveillance, this 24mm focal length lens from BOSHI Optical Technology maintains sharpness from center to edge. Its robust optical design supports consistent performance under varying temperatures, making it a dependable choice for OEM integrators who demand repeatable imaging quality without compromising on size or cost.

Manufactured by BOSHI Optical Technology, this 13mm F1.0 Uncooled Thermal Lens is optimized for the 8‑12μm long‑wave infrared band. This Thermal Imaging Lens is perfectly matched with 640×512 resolution detectors with 12μm Pixel dimension. Adopting F1.0 large aperture, the lens captures faint infrared radiation to deliver clear thermal outputs under low‑contrast scenes. Its front optical element reaches IP67 protection grade, and exposed surfaces are covered with durable AR coating to sustain stable performance in complicated outdoor surroundings. The focus covers 1 meter to infinity, and the working temperature spans from ‑40℃ to +80℃. The compact M20×0.5 Mount supports convenient assembly. BOSHI Optical Technology carries out strict optical calibration to guarantee stable and consistent optical quality for mass integration of thermal imaging devices.

Standard M12 16mm 1/2.7" F2.0 5MP Security CCTV Lens, and all products have been tested by MTF instruments, resulting in higher consistency compared to products from other suppliers. You can rest assured to purchase standard M12 lenses from our factory.

M12 2.85mm 1/2.9" F2.3 Security Lens PL071 — also known as the 2.85mm 1/2.9" F2.3 FPV Camera Lens PL071 — and all products have been tested by MTF instruments, resulting in higher consistency compared to products from other suppliers. You can rest assured to purchase standard M12 lenses from our factory.

2.8mm 1/2.7" Lens PL060| Factory Outlet BOSHI PL060 1/2.7 Sensor 5MP 2.8mm M12 Lens F/2.0 Smart Home Security Lenses for Fixed HD CCTV Camera is a high-quality camera lens designed specifically for fixed HD CCTV security systems and smart home applications. The PL060 model features a 1/2.7-inch sensor compatibility, offering 5 megapixel resolution for crystal-clear image capture. Its 2.8mm focal length provides a wide viewing angle, making it ideal for monitoring large areas with minimal blind spots. The lens uses an M12 mount, ensuring easy installation and compatibility with most standard CCTV cameras. With an aperture of F/2.0, the lens delivers excellent performance in low-light conditions, supporting enhanced night surveillance and reliable operation in various lighting environments. The BOSHI brand is known for robust manufacturing standards, providing durable and stable products that meet the needs of both residential and commercial surveillance applications. Key advantages include precise optics for HD imaging, sturdy construction, and simple integration into existing security setups. This lens is suitable for users seeking reliable image quality and wide coverage in fixed-position security cameras, and it contributes to smarter home security solutions by enabling better monitoring and peace of mind.

2.8mm 1/2.7" Standard M12 Lens PL099, and all products have been tested by MTF instruments, resulting in higher consistency compared to products from other suppliers. You can rest assured to purchase standard M12 lenses from our factory.
